Commissioning
Parameter setting with the E82ZBB diagnosis terminal
6
l
101 EDK82MV752 DE/EN/FR 7.1
6.3 Parameter setting with the E82ZBB diagnosis terminal
Description
The diagnosis terminal is available as an accessory. It is made of rubber and houses the
E82ZBC keypad. For connecting it to the controller, a separate E82ZWL connection cable is
required. A complete description of the keypad is included in the instructions supplied
together with the keypad.
Connecting the diagnosis terminal
Even during operation it is possible to connect the diagnosis terminal to the AIF interface
of the controller and disconnect it again.
As soon as the keypad is supplied with voltage, it carries out a selftest. The keypad is ready
for operation, when it is in display mode.
