Commissioning
Important controller codes
6
l
108 EDK82MV752 DE/EN/FR 7.1
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0002*
s
uSEr
(Continua
tion)
Transferring
parameter sets
with the keypad Keypad ð PAR1 (+ FPAR1) Overwrite selected parameter set
and, if required FPAR1, with the
corresponding data of the keypad
71 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
11 with all other function modules
Keypad
ð PAR2 (+ FPAR1)
72 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
12 with all other function modules
Keypad
ð PAR3 (+ FPAR1)
73 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
13 with all other function modules
Keypad
ð PAR4 (+ FPAR1)
74 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
14 with all other function modules
Controller
ð keypad Copy all available parameter sets
(PAR1 ... PAR4, if required FPAR1) into
the keypad
80 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
20 with all other function modules
Keypad
ð function module Only overwrite the module−specific
parameter set FPAR1 with the data of
the keypad
40 only with function module INTERBUS,
PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
Function module ð keypad Only copy the module−specific
parameter set FPAR1 into the keypad
50 only with function module INTERBUS,
PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
C0002*
s
uSEr
(Continua
tion)
Saving your own
basic setting 9 PAR1 ð own basic setting For the parameters of the controller
you can save an own basic setting
(e.g. the delivery status of your
machine):
1. Ensure that parameter set 1 is
active
2. Inhibit controller
3. Set C0003 = 3, confirm with
v
4. Set C0002 = 9, confirm with v,
the own basic setting is saved
5. Set C0003 = 1, confirm with v
6. Enable the controller
C0002*
s
uSEr
(Continua
tion)
Loading/copying
the own basic
setting By using this function you can also
just copy PAR1 into the parameter
sets PAR2 ... PAR4
5 own basic setting ð PAR1 Restore own basic setting in the
parameter set selected
6 own basic setting ð PAR2
7 own basic setting ð PAR3
8 own basic setting ð PAR4
