3.3.5 Rated data of the drive systems
Type SDSGSSR35 SDSGSSR47 SDSGSSR56
Input data
Power supply
Voltage (all details +/- 10%)
24 V
DC
42 V
DC
42 V
DC
230 V
AC
320 V
DC
230 V
AC
320 V
DC
Frequency [Hz] --- --- --- 50 --- 50 ---
Rated current I
in
9.6 A
DC
5.0 A
DC
5.7 A
DC
2.6 A
eff
1.08 A
DC
4.3 A
eff
1.82 A
DC
Rated power P
in
[W] 227 203 237 321 332 540 540
Apparent rated power S
in
[VA] --- --- --- 580 --- 980 ---
Max. current I
max.
15 A
DC
10 A
eff
8 A
DC
10 A
eff
8 A
DC
Control supply
Voltage (all details +/- 10%)
24 V
DC
Current [A
DC
] 0.2
Brake supply
Voltage (all details +/- 10%)
24 ( fault concerning bei U < 20 V or U > 28 V)
Current [A
DC
] Approx. 1
Output data
Output currents
Output voltage [V
AC
] 0 ... 16 0 ... 28 0 ... 210
Rated current of fundamental oscillation
I
Out
[Aeff]
8.4 4.5 4.7 1.1 1.78
Power factor of fundamental oscillation
cos ϕ
1
0.99 0.98 0.99
Max. current I
max
[Aeff] 13.5 4.5
Rated frequency [Hz] 100
Electr. rated real power P [W] 186 187 217 305 500
Electr. rated apparent power S [VA] 275 267 277 477 483 773 759
Mech. output data
Rated operating mode
s1
Rated power [W] 140 170 250 440
Rated torque [Nm] 0.45 0.8 1.4
Max. starting torque 3) 0.78 1.1 2.4 3.5 3.6
Max. torque 4) 0.65 0.80 1.0 1.5 1.8 2.7 2.8
Rated speed [min -1 ] 3000 2000 3000
Idle speed [min -1 ] 2) 5000 4500 2700 4300 4000
Rated efficiency
Inverter
0.82 0.92 0.87 0.93
Motor 0.75 0.77 0.82 0.88
Complete system 0.62 0.69 0.70 0.71 0.81
Motor data
Winding
Speed constant [V/1000min
-1 ] 3.7 6.54 10.5 49.6 54.4
Torque constant [Nm/A] 0.058 0.104 0.169 0.796 0.901
R
UV
[Ω] 0.26 0.77 0.94 18.7 6.8
L
line
[mH] 0.18 0.59 1.23 27.4 11.8
Insulation material class F
