Commissioning
With hand terminal
7
EDK71MMXXX−020 DE/EN/FR 5.0
109
L
Switch−on sequence Comment
9. Set rated motor current
(C0120/1 = motor 1)
(C0120/2 = motor 2)
start017
00
01 20 001
1
c d
j g f k i h PS  w x
z
y Rated motor current for I 2 t
monitoring
Accepts the value from the
stepping switch:
l If C0006 = 0, 2, 4, 6:
– Display only
l If C0006 = 1, 3, 5, 7:
– Rated current can be
set via C0120
10. Configure digital input signals
Lenze setting:
l C0410/1 = 1:
– X3/E1: motor 1 start/stop
l C0410/2 = 2:
– X3/E2: motor 2 start/stop or
change direction of rotation
l C0410/3 = 3:
– X3/E3: brake control
start039
00 1
04 10 001
1
c d
j g f k i h PS 
A
w x
z
y Linking external signal
sources with internal digital
signals
For additional setting
options, see the code table
(
^ 112)
11. Configure digital output signals
Lenze setting:
l C0415/1 = 3:
– X3/A1: status of motor 1
l C0415/2 = 4:
– X3/A2: status of motor 2 or
direction of rotation
l C0415/3 = 5:
– X3/A3: brake status
l C0415/4 = 25:
– X3/A4: Active error message
start040
00 3
04 15 001
1
c d
j g f k i h PS 
A
w x
z
y Output of status messages
to terminal or bus
For additional setting
options, see the code table
(
^ 112)
12. Set acceleration time t
ir
(C0012/1 = motor 1)
(C0012/2 = motor 2)
start038
00 0
00 12 001
1
c d
j g f k i h PS 
A
w x
z
y Time for voltage change
U
0
... U
mains
Accepts the value from
potentiometer "T"
l If C0006 = 0, 1, 2, 3:
– Display only
l If C0006 = 4, 5, 6, 7:
– Acceleration time can
be set via C0012
