Appendix
THROUGH-HOLE DRAWING FOR 15 HP (11 kW) AND 20 HP (15 kW) MODELS
This drawing applies to the following models only: SF2150F, SF4150F, SF5150F, SF4200F, and SF5200F.
HEATSINK
0.24 (6)
L
M
PANEL
CUTOUT
0.63 (16)
(left & right)
M
11.14 (283)
H
E
MOUNTING
HOLES (#8)
1.00 (25)
(top & bottom)
E
F
F
1.04
(26)
10.14 (258)
2.24
(57)
TOP
2.24
(57)
1.04
(26)
1.04
(26)
2.24
(57)
2.24
(57)
1.04
(26)
THROUGH-HOLE CUTOUT DIMENSIONS FOR 15 HP (11 kW) & 20 HP (15 kW) MODELS
HP (kW)
MODEL
H
E
F
L
M
15
(11)
SF2150F
18.09 (459)
6.03 (153)
3.02 (77)
0.50 (13)
2.52 (64)
SF4150F
15.59 (396)
6.63 (168)
3.31 (84)
0.22 (5.6)
0.95 (24)
SF5150F
15.59 (396)
6.63 (168)
3.31 (84)
0.22 (5.6)
0.95 (24)
20
(15)
SF4200F
18.09 (459)
6.03 (153)
3.02 (77)
0.50 (13)
2.52 (64)
SF5200F
18.09 (459)
6.03 (153)
3.02 (77)
0.50 (13)
2.52 (64)
