4 Commissioning
NOTE 1: Factory defaults are shown for a 60 Hz base frequency. refer to Parameter 48 for 50 Hz base frequency.
NOTE 2: Maximum setting is 999.9 Hz on drives with High Output Frequency option. Consult the factory.
NOTE 3: If LINE VOLTAGE is set to LOW, maximum setting is 150%.
NOTE 4: Maximum setting is 1300.0 Hz (factory default is 999.9) on drives with High Output Frequency option.
Consult the factory.
NO. PARAMETER NAME RANGE OF ADJUSTMENT
FACTORY
DEFAULT
(NOTE 1)
12
TB-13C FUNCTION
SELECT
NONE (01), 0-10 VDC (02), 4-20 mA (03),
PRESET SPEED #3 (04), INCREASE FREQ (05),
EXTERNAL FAULT (06), REMOTE KEYPAD (07),
DB FAULT (08), ACCEL/DECEL #2 (09)
NONE (01)
13 TB-15 OUTPUT (SEE PARAMETER 6 - TB-14 OUTPUT) NONE (01)
14 CONTROL
TERMINAL STRIP ONLY (01),
REMOTE KEYPAD ONLY (02),
TERMINAL STRIP OR REMOTE KEYPAD (03)
TERMINAL STRIP
ONLY (01)
15 SERIAL LINK
DISABLE (01)
9600, 8, N, 2 WITH TIMER (02),
9600, 8, N, 2 WITHOUT TIMER (03),
9600, 8, E, 1 WITH TIMER (04),
9600, 8, E, 1 WITHOUT TIMER (05),
9600, 8, O, 1 WITH TIMER (06),
9600, 8, O, 1 WITHOUT TIMER (07)
9600, 8, N, 2
WITH TIMER
(02)
16 UNITS EDITING
TENTHS OF UNITS M(01)
WHOLE UNITS (02)
WHOLE
UNITS (02)
17 ROTATION
FORWARD ONLY (01),
FORWARD AND REVERSE (02)
FORWARD
ONLY (01)
18
MOTOR OVERLOAD
TYPE
SPEED COMPENSATION (01)
NO SPEED COMPENSATION (02)
SPEED
COMPENSATION
(01)
19 ACCELERATION TIME 0.1 - 3600.0 SEC 20.0 SEC
20 DECELERATION TIME 0.1 - 3600.0 SEC 20.0 SEC
21 DC BRAKE TIME 0.0 - 3600.0 SEC 0.0 SEC
22 DC BRAKE VOLTAGE 0.0 - 30.0 % 0.00%
23 MINIMUM FREQUENCY 0.0 - MAXIMUM FREQUENCY 0.0 Hz
24 MAXIMUM FREQUENCY MINIMUM FREQ - 240.0 Hz (NOTE 2) 60.0 Hz
25 CURRENT LIMIT 30 - 180% (NOTE 3) 180%
26 MOTOR OVERLOAD 30 - 100 % 100%
27 BASE FREQUENCY 25.0 - 500.0 Hz (NOTE 4) 60.0 Hz
