Commissioning 4
4.3 Parameter Menu
NOTE: If the drive is equipped with the PI option, please refer to Appendix B for additional parameter
information.
NO. PARAMETER NAME RANGE OF ADJUSTMENT
FACTORY
DEFAULT
(NOTE 1)
01 LINE VOLTAGE HIGH (01), LOW (02) HIGH (01)
02 CARRIER FREQUENCY 4kHz (01), 6 kHz (02), 8 kHz (03), 10 kHz (04) 6 kHz (02)
03 START METHOD
NORMAL (01), START ON POWER UP (02),
START WITH DC BRAKE (03),
AUTO RESTART WITH DC BRAKE (04),
FLYING RESTART 1 (05),
FLYING RESTART 2 (06),
FLYING RESTART 3 (07)
NORMAL (01)
04 STOP METHOD
COAST (01), COAST WITH DC BRAKE (02),
RAMP (03), RAMP WITH DC BRAKE (04)
COAST (01)
05
STANDARD
SPEED SOURCE
KEYPAD (01), PRESET #1 (02),
0-10 VDC (03), 4-20 mA (04)
KEYPAD (01)
06
13 TB-14 OUTPUT
TB-15 OUTPUT
NONE (01), RUN (02), FAULT (03),
INVERSE FAULT (04), FAULT LOCKOUT (05),
AT SET SPEED (06), ABOVE PRESET #3 (07),
CURRENT LIMIT (08), AUTO SPEED (09),
REVERSE (10)
NONE (01)
08 TB-30 OUTPUT
NONE (01), 0-10 VDC FREQ (02),
2-10 VDC FREQ (03), 0-10 VDC LOAD (04),
2-10 VDC LOAD (05)
NONE (01)
09 TB-31 OUTPUT
NONE (01), 0-10 VDC LOAD (02)
2-10 VDC LOAD (03), DYNAMIC BRAKING (04)
NONE (01)
10
TB-13A FUNCTION
SELECT
NONE (01), 0-10 VDC (02), 4-20 mA (03),
PRESET SPEED #1 (04),RUN REVERSE (05),
START REVERSE (06), EXTERNAL FAULT (07),
REMOTE KEYPAD (08), DB FAULT (09),
AUXILIARY STOP (10), ACCEL/DECEL #2 (11)
NONE (01)
11
TB-13B FUNCTION
SELECT
NONE (01), 0-10 VDC (02), 4-20 mA (03),
PRESET SPEED #2 (04), DECREASE FREQ (05),
JOG FORWARD (06), JOG REVERSE (07)
AUXILARY STOP (08)
NONE (01)
NOTE 1: Factory defaults are shown for a 60 Hz base frequency. Refer to Parameter 48 for 50 Hz base frequency.
