2technical data – Lenze SCF frequency inverter User Manual
Page 10
10
Lenze 13466146 EDBSF01 v24 EN
2
Technical Data
dimensions: inches (millimeters)
HP
kW
INPUT
VOLTAGE
MODEL
H
W
D
P
1
0.75
208 / 240
SF210YF
7.72 (196)
6.80 (173)
4.55 (116)
1.20 (30)
208 / 240
SF210F
7.72 (196)
6.80 (173)
4.55 (116)
1.20 (30)
400 / 480
SF410F
7.72 (196)
6.80 (173)
4.55 (116)
1.20 (30)
480 / 590
SF510F
7.72 (196)
6.80 (173)
4.55 (116)
1.20 (30)
1.5
1.1
208 / 240
SF215YF
7.72 (196)
6.80 (173)
4.75 (121)
1.20 (30)
208 / 240
SF215F
7.72 (196)
6.80 (173)
4.55 (116)
1.20 (30)
400 / 480
SF415F
7.72 (196)
6.80 (173)
4.55 (116)
1.20 (30)
2
1.5
208 / 240
SF220YF
7.72 (196)
6.80 (173)
4.75 (121)
1.20 (30)
208 / 240
SF220F
7.72 (196)
6.80 (173)
4.55 (116)
1.20 (30)
400 / 480
SF420F
7.72 (196)
6.80 (173)
4.55 (116)
1.20 (30)
480 / 590
SF520F
7.72 (196)
6.80 (173)
4.55 (116)
1.20 (30)
3
2.2
208 / 240
SF230YF
7.72 (196)
8.54 (217)
5.30 (135)
1.75 (44)
208 / 240
SF230F
7.72 (196)
8.54 (217)
5.10 (130)
1.75 (44)
400 / 480
SF430F
7.72 (196)
8.54 (217)
5.10 (130)
1.75 (44)
480 / 590
SF530F
7.72 (196)
8.54 (217)
5.30 (135)
1.75 (44)
5
3.7
208 / 240
SF250YF
9.59 (244)
11.14 (283)
7.65 (194)
3.60 (91)
208 / 240
SF250F
7.72 (196)
8.54 (217)
6.30 (160)
2.75 (70)
400 / 480
SF450F
7.72 (196)
8.54 (217)
6.30 (160)
2.75 (70)
480 / 590
SF550F
7.72 (196)
8.54 (217)
6.30 (160)
2.75 (70)
7.5
5.5
208 / 240
SF275F
11.59 (294) 11.14 (283)
7.65 (194)
3.60 (91)
400 / 480
SF475F
9.59 (244)
11.14 (283)
7.65 (194)
3.60 (91)
480 / 590
SF575F
9.59 (244)
11.14 (283)
7.65 (194)
3.60 (91)
10
7.5
208 / 240
SF2100F
15.59 (396) 11.14 (283)
7.65 (194
)
3.60 (91)
400 / 480
SF4100F
11.59 (294) 11.14 (283)
7.65 (194)
3.60 (91)
480 / 590
SF5100F
11.59 (294) 11.14 (283)
7.65 (194)
3.60 (91)
15
11
208 / 240
SF2150F
18.09 (459) 11.14 (283)
8.29 (211)
3.60 (91)
400 / 480
SF4150F
15.59 (396) 11.14 (283)
8.29 (211)
3.60 (91)
480 / 590
SF5150F
15.59 (396) 11.14 (283)
8.29 (211)
3.60 (91)
20
15
400 / 480
SF4200F
18.09 (459) 11.14 (283)
8.29 (211)
3.60 (91)
480 / 590
SF5200F
18.09 (459
)
11.14 (283)
8.29 (211)
3.60 (91)
25
18.5
400 / 480
SF4250F
28.50 (724
)
10.34 (263)
8.39 (213)
3.70 (94)
480 / 590
SF5250F
28.50 (724) 10.34 (263)
8.39 (213)
3.70 (94)
NOTE: Refer to Appendix A for mounting template dimensions for the Through-hole Mount option.
