Electrical installation
Control connection X26
4
l
55 EDKCSCK002 DE/EN/FR 1.1
4.3 Control connection X26
Terminal assignment
Terminal Function Electrical data
X26
Connection for bridging the charging current
limitation 21.8 ... 30 V DC,
max. 1.5 A
ƒ The charging current limitation is bridged if X26 = HIGH (24 V DC).
ƒ The polarity does not influence the function of the charging current
limitation.
Cable cross−sections and screw−tightening torques
Cable type Wire end ferrule Possible cable
cross−sections Tightening torque Stripping
length
Flexible Without wire end ferrule
0.2 ... 2.5 mm 2
(AWG 24 ... 12)
0.5 ... 0.8 Nm
(4.4 ... 7.1 lb−in)
5 mm
For control cables, we recommend a cable cross−section of 0.25 mm 2 !
