Electrical installation
Power connections
4
l
52 EDKCSCK002 DE/EN/FR 1.1
4.2 Power connections
(
Stop!
ƒ The capacitor module is approved exclusively for operation at
symmetrical mains. An operation at external conductor−earthed
mains is not permissible.
ƒ Observe the maximum permissible mains voltage. A higher voltage
destroys the capacitor module.
ƒ The discharge current to earth (PE) is > 3.5 mA AC or > 10 mA DC.
According to EN 50178, a fixed installation is required. The
PE connection must be made according to EN 50178.
ƒ All power connections are designed as pluggable and coded. The connectors
are part of the ECSZA000X0B capacitor module accessories set. It must be
ordered separately.
ƒ Installation of cables acc. to EN 60204−1.
ƒ The cables used must comply with the approvals required for the respective
application (e.g. VDE, UL, etc.).
Terminal assignment
Terminal Function Electrical data
X23 DC−bus voltage connection
X23/+UG
Positive supply of DC−bus voltage
Application and type−dependent
0 ... 770 V
up to 24.5 A (
^ 44)
X23/+UG
X23/−UG
Negative supply of DC−bus voltage
X23/−UG
X23/PE
Earth connection
X23/PE
Cable cross−sections and screw−tightening torques
Cable type Wire end ferrule Possible cable
cross−sections Tightening torque Stripping
length
Terminal strip X23
Rigid −
0.2 ... 10 mm 2
(AWG 24 ... 8)
1.2 ... 1.5 Nm
(10.6 ... 13.3 lb−in)
5 mm
Flexible
Without wire end ferrule
0.2 ... 10 mm 2
(AWG 24 ... 8)
With wire end ferrule
0.25 ... 6 mm 2
(AWG 22 ... 10)
With TWIN wire end
ferrule 0.25 ... 4 mm 2
(AWG 22 ... 12)
