Electrical installation
Power connections
l
53
EDKCSCK002 DE/EN/FR 1.1
Shielded cables
Observe the following to increase the effect of shielded cables:
ƒ
Good shield connection
–
Ensure a contact surface as large as possible
ƒ
Low shield resistance
–
Only use shields with tin−plated or nickel−plated copper braids (shields
with steel braids cannot be used).
ƒ
High overlap rate of the braid
–
At least 70 ... 80 % with 90° overlap angle
The shield mounting kit ECSZS000X0B001 contains shield clamps.
