Scope of supply, Connections and interfaces – Lenze ECSCKxxx User Manual
Page 32
l
32
EDKCSCK002 DE/EN/FR 1.1
Scope of supply
Position
Description
Number
0
Capacitor module ECSCKxxx
1
1
Accessory kit with fixing material
1
Mounting instructions
1
Drilling jig
1
)
Note!
The ECSZK000X0B connectors must be ordered separately.
Connections and interfaces
Position
Description
Detailed
information
X23
Connections
l
DC−bus voltage
l
PE
X26
Control connection
l
Bridging of the charging current limitation
