Lieferumfang, Anschlüsse und schnittstellen, Hinweis – Lenze ECSCKxxx User Manual
Page 4
l
4
EDKCSCK002 DE/EN/FR 1.1
Lieferumfang
Position
Beschreibung
Anzahl
0
Kondensatormodul ECSCKxxx
1
1
Beipack mit Befestigungsmaterial
1
Montageanleitung
1
Bohrschablone
1
)
Hinweis!
Die Steckverbinder ECSZK000X0B müssen gesondert bezogen werden.
Anschlüsse und Schnittstellen
Position
Beschreibung
ausführliche
Informationen
X23
Anschlüsse
l
Zwischenkreisspannung
l
PE
X26
Steueranschluss
l
Überbrückung der Ladestrombegrenzung
