6 Electrical installation
EMF2102IBC−V004 with diagnosis terminal (LECOM−A)
EDKMF2102 DE/EN/FR 7.1
68
l
H2_V004_mitHandterminalLecomA−gummiente
How to wire the components:
1. Connect communication module to PC via PC system cable
.
2. Insert connecting cable ‚ into diagnosis terminal.
3. Remove plug ƒ from heatsink.
4. Insert connecting cable ‚ into the AIF interface of the controller.
5. If the mains voltage is switched on, the communication module is now ready for
operation.
You can now communicate with the controller for commissioning, i.e. you can read all codes
and change the writable codes.
)
Note!
The communication module can be plugged in, removed and parameterised
during operation.
