Technical data
General data and operating conditions
4
EDKMF2102 DE/EN/FR 7.1
55
l
H1_Daten−abmess
4 Technical data
General data and operating conditions
Area Communication module EMF2102IBC
−V001 −V002 −V003 −V004 /
E82ZBL−C
Communication
media RS232 (LECOM−A)
RS485 (LECOM−B)
RS485 (LECOM−B) Optical fibre
(LECOM−LI)
RS232 (LECOM−A)
Current consumption 80 mA 60 mA 70 mA −
Protocol LECOM−A/B V2.0
Character format 7 bit ASCII; 1 stop bit; 1 start bit; 1 parity bit (even)
Baud rate [bits/s] 1200, 2400, 4800, 9600, 19200
Type of protection IP20
Ambient
temperature During
operation: 0 °C ... +55 °C
Transport: − 25 °C ... +70 °C
Storage: − 25 °C ... +60 °C
Climatic conditions Class 3K3 to EN 50178
(without condensation, average relative humidity 85 %)
External DC voltage supply (plug connector 24V DC)
U
eff
= 15 to 30 V DC; w = 5%
U eff = 20 to 25 V DC; w = 48%; U ss < 35 V
