4 Technical data
Protective insulation
EDKMF2102 DE/EN/FR 7.1
56
l
H1_Daten−abmess
Protective insulation
Protective insulation between
bus and ... Type of insulation for communication module EMF2102IBC
−V001 −V002 −V003 −V004 / E82ZBL−C
Reference earth / PE Functional insulation Not required Functional
insulation
External supply Functional insulation Reinforced
insulation −
Power section
820X / 821X Basic insulation Reinforced
insulation Basic insulation
822X / 8200 vector Reinforced insulation Reinforced
insulation
93XX / 9300 Servo PLC
ECS servo system
Control terminals
820X / 8200 vector Functional insulation Reinforced
insulation Functional
insulation
821X
822X Basic insulation Basic insulation
Drive PLC
93XX / 9300 Servo PLC
ECS servo system Reinforced insulation Reinforced
insulation
