Electrical installation

Wiring according to EMC

6

EDKMF2102 DE/EN/FR 7.1

61

l

H2_EMV_Verdraht−EMV

Wiring according to EMC

For wiring according to EMC requirements observe the following points:

)

Note!

ƒ

Separate control/data cables from motor cables.

ƒ

In case of digital signals, connect the shields of control/data cables on both
sides.

ƒ

Use an equalizing conductor with a cross−section of at least 16 mm

2

to

avoid potential differences between the bus nodes (reference: PE).

ƒ

Observe the other notes concerning EMC−compliant wiring given in the
documentation for the standard device.
