84
Error messages
Possible causes and remedies
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
EtherNet/IP: Invalid Configuration [0x01bc6430]
EtherNet/IP: Invalid IP Parameters [0x01bc6533]
EtherNet/IP: Fault Mode [0x01bc8111]
EtherNet/IP: Explicit Message Timeout [0x01bc8112]
EtherNet/IP: Overall Ethernet Timeout [0x01bc8114]
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Module configuration is faulty. Check and correct module configuration.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
One or more IP parameters are faulty. Check and correct IP configuration.
 Setting the IP configuration of the Inverter Drive 8400
motec ( 30)
Response (Lenze setting printed in bold) Setting: C13880/2
 No reaction  System fault  Fault  Trouble  TroubleQuickStop  WarningLocked  Warning  Information
Cause Remedy
• Connection to scanner has been interrupted.
• Controlling I/O connection failed by timeout.
• Within the timeout time for implicit messages
parameterised by the scanner, no "implicit messages"
have been received.
• Check cables and terminals.
• Plug the network cable into the EtherNet/IP terminal.
• Check Requested Package Interval (RPI) of I/O
connection.
• Increase timeout time for implicit messages.
Response (Lenze setting printed in bold) Setting: C13880/3
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
• Connection to scanner has been interrupted.
• Failure of an explicit connection
• Within the timeout time for explicit messages
parameterised by the scanner, no "explicit messages"
have been received.
• Check cables and terminals.
• Plug the network cable into the EtherNet/IP terminal.
• Check Requested Package Interval (RPI) of the explicit
connection.
• Increase timeout time for explicit messages.
Response (Lenze setting printed in bold) Setting: C13880/4
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
• Failure of »Engineer« communication via Ethernet
• When the time set in C13881 has expired, there is no
access via the »Engineer«.
• Check cables and terminals.
• Plug in network cable.
• Increase the overall Ethernet timeout time in C13881 .
 Fault with regard to EtherNet/IP communication
( 77)
