Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 2.0 - 10/2013
30
Commissioning
Setting the IP configuration of the Inverter Drive 8400 motec
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6.3 Setting the IP configuration of the Inverter Drive 8400 motec
The IP configuration is required for addressing the Inverter Drive 8400 motec to ensure that
communication between the PC/»Engineer« or the scanner and the drive can be effected via
EtherNet/IP. For this, an IP address, subnet mask, and gateway address must be allocated. You have
the following options to select the IP parameters for the Inverter Drive 8400 motec:
• Setting via the EtherNet/IP configurator of the »Engineer« ( 31)
• Setting via codes in the »Engineer« ( 33)
• Setting via a BOOTP/DHCP server ( 35)
• Setting via the TCP/IP Interface Object (0xF5) ( 35)

Note!
• The assignment of invalid combinations of IP address, subnet mask, and gateway
address can have the consequence that no connection to the EtherNet/IP network can
be established.
• Codes C13010 (IP address), C13011 (subnet mask), C13012 (gateway address), and
C13016 (multicast IP address) show the IP parameters currently used.
• In the case of impermissible settings, the error message EtherNet/IP: Invalid IP
Parameters [0x01bc6533] ( 84) is output.
