Product description
Connections and interfaces
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
• By default, the EtherNet/IP connections and the LEDs for the EtherNet/IP status displays are
already mounted and wired:
• EtherNet/IP connection A2 to plug connector X31
• EtherNet/IP connection A3 to plug connector X32
• LEDs on plug connector X55
• At positions A1 ... A4 and B1 ... B4, it is also possible to design the EtherNet/IP connections and
other connections (e.g. digital inputs) freely.
• For the connections, 5-pin M12 connectors or - alternatively - cable glands (cable cross-section
max. 1.0 mm 2 , AWG 18) can be used.
• The M12 connectors, cable glands and prefabricated system cables can be obtained from
various manufacturers.
• Wire the M12 connectors or cable glands used to the corresponding contacts of the terminal
strips/plug connectors X3, X4 and X61.

Hardware manual for Inverter Drives 8400 motec
Observe the notes and wiring instructions contained in this documentation.
