Mechanical installation

Mounting steps

4

l

45

EDK94ZPP0364 DE/EN/FR/ES/IT 2.1

4.3

Mounting steps

Proceed as follows for the installation:
1. Prepare M5 threaded holes on the mounting plate according to the

mounting grid.

2. Screw the installation backplane onto the mounting plate. Do not yet

tighten the screws.

–

Use M5 screw and washer assemblies or M5 hexagon socket screws
with washers.

–

The screw joint in the installation backplane may not jut out more than
7 mm.

3. Repeat step 2 for other installation backplanes, which can be mounted

directly adjacent to one another.

4. Align all installation backplanes.
5. If busbars are used: connect the busbars.
6. Tightly screw all installation backplanes onto the mounting plate.

–

Tightening torque: 3.4 Nm (30 lb−in).
