Page 39: 4mechanical installation

Mechanical installation
Dimensions
4
l
39
EDK94ZPP0364 DE/EN/FR/ES/IT 2.1
4
Mechanical installation
4.1
Dimensions
Mounting grid
We recommend to provide the mounting plate with a grid pattern of M5
threaded holes for attaching the devices. This preparation enables easy
attachment of the devices, and the device sizes 1, 2, ... n can thus be mounted
directly adjacent to each other.
SSP94PN010
0
Mounting with backplane for attaching the power supply module
2
Grid hole pattern for installation backplane
3
Grid hole pattern for other device sizes or built−on/footprint filters (only Single
Drive)
4
Cable duct
