12 Error messages
12.2 Possible causes and remedies
98
Lenze · E84AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 10/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
EtherNet/IP: Internal Error [0x01bc6011]
EtherNet/IP: Internal Error [0x01bc6100]
EtherNet/IP: Internal Error [0x01bc6101]
EtherNet/IP: Invalid Parameter Set [0x01bc641f]
EtherNet/IP: Error: Lenze Setting Loaded [0x01bc6420]
EtherNet/IP: Invalid Configuration [0x01bc6430]
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Communication module is defective. Send communication module with error description to
Lenze.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Communication module is defective. Send communication module with error description to
Lenze.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Communication module is defective. Send communication module with error description to
Lenze.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
No active parameter set could be loaded. • Download application again (including module).
• Send communication module together with a
description of the fault to Lenze.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Access to parameter set was not possible. • Download application again (including module).
• Send communication module together with a
description of the fault to Lenze.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Module configuration is faulty. Check and correct module configuration.
