Lenze · E84AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 10/2013 · TD17
109
13
Parameter reference
13.1
Parameters of the communication module
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13012
C13016
Parameter | Name:
C13012 | Active Gateway Address
Data type: UNSIGNED_8
Index: 11563 = 0x2D2B
Display of the active gateway address
(Instance attribute 5 (Gateway Address) in the
TCP/IP Interface Object (245 / 0xF5) ( 141)
Display range
(min. value | unit | max. value)
0
255
Subcodes
Info
C13012/1
Active gateway address (most significant byte)
C13012/2
Active gateway address
C13012/3
Active gateway address
C13012/4
Active gateway address (least significant byte)
Read access Write access CINH PLC STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13016 | Active Multicast IP Address
Data type: UNSIGNED_8
Index: 11559 = 0x2D27
Display of the active multicast IP address
Display range
(min. value | unit | max. value)
0
255
Subcodes
Info
C13016/1
Multicast IP address (most significant byte)
C13016/2
Multicast IP address
C13016/3
Multicast IP address
C13016/4
Multicast IP address (least significant byte)
Read access Write access CINH PLC STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
