6 Commissioning
6.2 Configuring the host system (scanner)
36
Lenze · E84AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 10/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6.2 Configuring the host system (scanner)
To be able to communicate with the communication module, the host (scanner) must be configured
first.
The configuration of EtherNet/IP networks always requires an EtherNet/IP configuration software
(e.g. »RSLogix 5000« from Rockwell) for the host system (scanner).
The configuration software is necessary for the programming of controller programs, EtherNet/IP
configuration, real-time execution and diagnostics.
The basic parameters of the communication module are stored in the internal configuration
memory and can be used for node detection by the scanner.
For node detection (fieldbus scan), the corresponding device descriptions of the Lenze device family
are used.

Tip!
Here you will find information on configuring with the »RSLogix 5000« programming
software from Rockwell:
 I/O configuration with »RSLogix 5000« version 19 or lower ( 68)
 I/O configuration with »RSLogix 5000« version 20 or higher ( 73)
