4 Technical data
4.1 General data and operating conditions of the EtherNet/IP
16
Lenze · E84AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 10/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4 Technical data
4.1 General data and operating conditions of the EtherNet/IP
Range Values
Order designation E84AYCEO
Communication profile EtherNet/IP
Communication medium S/FTP (Screened Foiled Twisted Pair), ISO/IEC 11801 or EN 50173, CAT 5e
Interface for communication RJ45 Standard Ethernet (according to IEEE 802.3), 100Base-TX (Fast
Ethernet)
Network topology Tree, star, and line
Type of node Adapter (slave)
Number of nodes Max. 254 in the subnetwork
Max. cable length 100 m
Vendor ID 587 (0x24B), Lenze (’Lenze AC Tech’ in older Rockwell data)
Device type 2 (0x02), AC Drive
Product code 8400 (0x20D0)
Baud rate • 10 Mbps
• 100 Mbps
Transmission mode Half duplex / full duplex
Switching method Store-and-forward / cut-through
Switch latency Approx. 125 μs at max. telegram length
Voltage supply External supply via separate power supply unit
• + : U = 24 V DC (20.4 ... 28.8 V), I
max
= 140 mA
• - : Reference potential for external voltage supply
Conformities , approvals • CE
• UL
(see also hardware manual)

Hardware manual for Inverter Drives 8400
Here you can find the ambient conditions and data on the electromagnetic compatibility
(EMC), which also apply to the communication module.
