C13017
C13018
C13019
Parameter | Name:
C13017 | Ethernet Config Control
Data type: UNSIGNED_16
Index: 11558 = 0x2D26
Setting of the baud rate for the Ethernet connections
Dependent on the configuration of the Ethernet port of the device to be connected, we recommend the use of a
cross-over cable.
Selection list
0 Auto-Negotiation
1 10 Mbps
2 100 Mbps
3 Reserved
4 Reserved
5 10 Mbps/Half Duplex
6 10 Mbps/Full Duplex
7 100 Mbps/Half Duplex
8 100 Mbps/Full Duplex
9 Reserved
10 Reserved
11 Reserved
12 Reserved
Subcodes
Lenze setting
Info
C13017/1
0: Auto-Negotiation
Ethernet setting port X259
C13017/2
0: Auto-Negotiation
Ethernet setting port X260
Read access Write access CINH PLC STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13018 | Multicast Config Alloc Control
Data type: UNSIGNED_8
Index: 11557 = 0x2D25
Selection for multicast IP addressing via instance attribute 9 (Mcast Config) in the
TCP/IP Interface Object (245 /
Selection list
(Lenze setting printed in bold)
0 Default Allocation Algorithm
1 Multicast IP Start Address
Read access Write access CINH PLC STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13019 | Multicast Config TTL Value
Data type: UNSIGNED_8
Index: 11556 = 0x2D24
Setting of the multicast TTL value for the validity time of data packets in the EtherNet/IP network
(Instance attribute 8 (TTL Value) in the
TCP/IP Interface Object (245 / 0xF5) ( 141)
Setting range
(min. value | unit | max. value)
Lenze setting
1
255 1
Read access Write access CINH PLC STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
