Commissioning
Code Possible Settings
IMPORTANT
No. Name Lenze Selection
C37 Fixed setpoint 1
(JOG 1)
20.0 0.0 {Hz} 240
C38 Fixed setpoint 2
(JOG 2)
30.0 0.0 {Hz} 240
C39 Fixed setpoint 3
(JOG 3)
40.0 0.0 {Hz} 240
C46 Frequency setpoint
0.0 {Hz} 240 Display: Setpoint via CANopen, analog
input, or function UP/DOWN
C50 Output frequency 0.0 {Hz} 240 Display
C53 DC bus voltage 0.0 {%} 255 Display
C54 Motor current
0.0 {%} 255 Display
C87 Motor rated speed
1390 300 {RPM} 32000 Set to motor nameplate speed
C89 Motor rated
frequency
50 10 {Hz} 1000 Set to motor nameplate frequency
C90 Input voltage
selection
0 Auto Automatically sets to Low (1) or High (2)
upon next power-up, depending on input
voltage
1 Low For 200 V or 400 V input
2 High For 240 V or 480 V input
NOTE
• To simplify commissioning, the Lenze setting is preset at the factory, depending on
model:
C90 = 1 for 400/480 V models
C90 = 2 for 230/240 V models
• Upon reset (C02 = 1, 2), C90 = 0. Confirm correct setting after next power-up.
C94 User password
0 0 999
Changing from “0” (no password), value
will start at 763
When set to a value other than 0,
must enter password at C00 to access
parameters
C99 Software version
Display, format: x.yz
c06 Holding time -
automatic DC
injection brake
(Auto-DCB)
0.0 0.0 {s} 999
0.0 = not active
999 = continuous brake
• Automatic motor braking below 0.1 Hz
by means of motor DC current for the
entire holding time (afterwards: U, V, W
inhibited)
• Confirm motor suitability for use with DC
braking
c08 Analog output
scaling
100 1.0 999 When 10 VDC is output at terminal 62, it
will equal this value (see c11)
c11 Configuration -
Analog output (62)
0 0 None
1 Output frequency 0-10 VDC
Use c08 to scale signal
Example:
c11 = 1 and c08 = 100:
At 50 Hz, terminal 62 = 5 VDC
At 100 Hz, terminal 62 = 10 VDC
2 Output frequency 2-10 VDC
3 Load 0-10 VDC
4 Load 2-10 VDC
5 CANopen Control
Value set by RPDO (h66,h76 = 4)
(c08 not used for scaling)
