Lenze SMD 0-37kW-22kW Full I/O - Manual (Page 16)

16 Lenze 13466183 EDBSC03 v7
Commissioning
Code Possible Settings
IMPORTANT
No. Name Lenze Selection
CE1 Configuration -
Digital input E1
1 1 Activate fixed setpoint 1 (JOG1)
2 Activate fixed setpoint 2 (JOG2)
• Use C37...C39 to adjust fixed setpoints
• Activate JOG3: Both terminals = HIGH
3 DC braking (DCB) See also C36
4 Direction of rotation LOW = CW rotation
HIGH = CCW rotation
5 Quick stop Controlled deceleration to standstill, active
LOW; Set decel rate in C13
6 CW rotation CW rotation = LOW and CCW rotation =
LOW: Quick stop; Open-circuit protected
CE2 Configuration -
Digital input E2
4 7 CCW rotation
8 UP (setpoint ramp-up)
9 DOWN (setpoint ramp-down)
UP = LOW and DOWN = LOW: Quick
stop; Use momentary NC contacts
10 TRIP set Active LOW, triggers EEr (motor coasts
to standstill)
NOTE: NC thermal contact from the motor
can be used to trigger this input
11 TRIP reset See also c70
12 No action can be used if Ex inputs are used only as
CANopen digital inputs
CE3 Configuration -
Digital input/output
E3
3 1...12 (same as above)
13...19 (reserved)
20 Ready
21 Fault
22 Motor is running
23 Motor is running - CW rotation
24 Motor is running - CCW rotation
25 Output frequency = 0 Hz
26 Frequency setpoint reached
27 Threshold (C17) exceeded
• 1...11 configures terminal E3 as an input
• 20...30 configures terminal E3 as a
current-sourcing (PNP) output rated 12
VDC / 50 mA
28 Current limit reached • in either motor or generator mode
29 Dynamic Braking
30 CANopen Control
• output controlled by RPDO (h66,h76 = 4)
NOTE
A CFG fault will occur under the following conditions:
• E1...E3 settings are duplicated (each setting can only be used once)
• One input is set to UP and another is not set to DOWN, or vice-versa
C08 Configuration -
Relay output
(terminals K14 and
K12)
1 Relay is energized if
0 Ready
1 Fault
2 Motor is running
3 Motor is running - CW rotation
4 Motor is running - CCW rotation
5 Output frequency = 0 Hz
6 Frequency setpoint reached
7 Threshold (C17) exceeded
8 Current limit reached in either motor or generator mode
9 CANopen Control Output controlled by RPDO (h66,h76 = 4)
C10 Minimum output
frequency
0.0 0.0 {Hz} 240 • Output frequency at 0% analog setpoint
• C10 not active for fixed setpoints or
setpoint selection via c40
