Leica IC80 HD
IC80 HD Digital Camera
Ϙ
Weight700g(cameraonly)
Ϙ
Exposuretime2msec.–2sec.
Ϙ
Liveimageoncomputerscreenupto25fps(1024×768pixels)
Ϙ
LiveimageonHDMIscreenupto45fps(1280x760pixels)
Ϙ
LiveimageonHDMIscreenupto20fps(1920x1080pixels)
Ϙ
Full-screenimagecapture2048×1536pixels,3.1megapixels
Ϙ
Sensorsize:6.55 mm×4.92 mm
Ϙ
Pixelsize:3.2μm×3.2μm
Sensor
Ϙ
Sensortype:Micron1/2"CMOS
Ϙ
Gain1Ч–20Ч
Ϙ
Colordepth24-bit
Ϙ
FileformatsJPEG/MP4
Software
Operatingsystems:WindowsXP,WindowsVista
Leicasoftware:LASEZSoftware(PC)
Mechanical and optical interfaces
Ϙ
FitsbetweentubeandstandviastandardLeicadovetail
Ϙ
Midpointoffsetbetweentopandbottomof
dovetail< 0.4 mm
Ϙ
Lightdistributionoptical50%/camera50%
Ϙ
Novisiblereflections,dustordirtontheprism
Ϙ
Internalvideomagnification0.5×
Ϙ
Sensorcenteredonopticalaxis±0.1 mm
Ϙ
Sensoralignedhorizontally/vertically±1degree
Electronic interfaces
Ϙ
Compatibility:USB2.0minisocket
Ϙ
Analogvideoport(RCAplug)PALorNTSCcompositevideosignal
Ϙ
PinholeswitchfortogglingbetweenPALandNTSCvideomode
Ϙ
2-colorLEDforpoweron(green)/imagecapture(red)
Ϙ
IntegratedSDslot(SecureDigital)
Ϙ
Captureswitchforimageacquisition
Ϙ
Resetfunctionwhencaptureswitchispressedlongerthan
10seconds
