Leica IC80 HD Manual 26
Theimagecannotbeoutputviaboththe
HDMI and analog ports simultaneously.
The HDMI port always has priority. To output
the image via the analog port, you have to
removetheHDMIcablefromthecamera.
Connection
1. Plug the power cable into the correspon-
dingconnectorontherearsideoftheLeica
IC80HDandtheotherendintoasuitable
powersocket.
2. Plug the video cable into the "Video"
port on the rear side of the Leica
IC80HDandtheotherendintotheanalog
port of the device (projector, monitor,
recorderetc.).
Changing the video standard
Ifyouseeadistortedimageornoimage
at all on your analog device, you may
havetochangethevideostandard.
1. To change between the "PAL" and "NTSC"
videostandards,carefullypressthetoggle
button once using the tip of a pen or
pencil.
Analog Video Display without a Computer
