Effective displayed section, Effectivedisplayedsection – Leica Biosystems IC80 HD User Manual
Page 10
Leica IC80 HD
Manual
10
Duetothesensorsizeinthecamera,the
liveimageandthefinalimagecapturedo
notshowthesamesectionthatyouseewhen
lookingthroughtheeyepieces.
Using the optional graticule
Theoptionalgraticulecanbeinsertedintothe
eyepiece and shows the section of the live or
capturedimage.
Effective Displayed Section
Liveimage1920×1080(16:9)
Capturedimage2048Ч1536(4:3)
