Assembling the camera, Assemblingthecamera – Leica Biosystems IC80 HD User Manual
Page 13
Leica IC80 HD
Manual
13
The Leica IC80 HD is installed between
themicroscopestandandtube.
TheLeicaIC80HDiscompatiblewithall
LeicaMseriesstereomicroscopes.
If
thetubeofthemicroscopeisalready
installed,removeitaccordingtotheUser
Manualprovidedwiththemicroscope.
Assembly
1. Loosen the locking screw on the optics
carrier.
2 Place the Leica IC80 HD on the optics
carrier.
3. Tightenthelockingscrewcarefullywithout
applyingtoomuchforce.
4. Install
the
tube
on
the
Leica
IC80HDasdescribedinthemanualforyour
stereomicroscope.
Assembling the Camera
