Leica IC80 HD
Manual
19
Thestand-alonekitisdesignedforthe
useofHDMI-capablemonitorsandtele-
visions. We urgently recommend not using a
DVIadapter,asotherwiseproperfunctioncan
nolongerbeguaranteed!
Ifthereisasimultaneousanalogconnec-
tion,onlytheHDMIsignalisoutput.
Please pay ultimate attention to only
connect the 5V power supply which is
part of the stand-alone kit. Applying a wrong
voltage can severely damage the IC80 HD
camera!
Cables
1. Connect the Leica IC80 HD to a suitable
powersocketusingthepowerpack.
2. ConnectthenarrowendoftheHDMIcable
providedusingthecamera.
3. ConnectthewideendoftheHDMIcableto
theHDMIinputofthetelevisionormonitor.
Cables and Terminals
