Landoll ICON 1632RS Grader - Manual (Page 30)

6-6 F-740-1213 Edition
ILLUSTRATED PARTS LIST
Grader Assembly
ITEM PART NO. DESCRIPTION QTY.
1 1-512-010010-11 NUT, HEX 5/8-11 GR8 2
2 155971 PIN, SPRING CLIP 25
3 1-654-010047-07 SCREW, HEX HEAD CAP 1/4-20 X 1-1/4 GR5 8
4 1-654-010055-09 SCREW, HEX HEAD CAP 1/2-13 X 3 GR5 2
5 1-654-010125-20 SCREW, HEX HEAD CAP 1-8 X 7-1/2 GR8 1
6 1-654-010125-22 SCREW, HEX HEAD CAP 1-8 X 8-1/2 GR8 1
7 110-0238 NUT, ESNA 3/4-10 1
8 118652 NUT, HEX LOCK 1-8 2
9 ICO2189 TRANSPORT STRAP 1
10 134912 PIN, LYNCH 1/4 X 1-1/4 12
11 140647 JACK, SIDEWIND 7,000# (SEE PAGE 6-14) 1
12 1408090 CLEVIS PIN .375 X 4 1
13 622-3511-010 WASHER, FLAT, 1MIL-CARB SAE 3
14 ICO2182 1632 MOW BOARD 1
ICO2205 1432 MOW BOARD 1
15 172791 BOLT, PLOW 5/8-11 X 2 GR8 20
16 4001244 TIRE, 19 X 16.1 2
17 4001245 RIM, 16 X 16.1 2
18 ICO0361 HUB AND AXLE ASSEMBLY (SEE PAGE 6-12) 2
19 ICO0477 CYLINDER PIN, 1” (LIFT) 2
20 4001442 PIN, SAFETY 3/4 X 3 GR8 1
21 4001443 PIN, BRIDGE 5/32 X 3 1
22 ICO0026 REAR SIDE PIPE CLAMP 1
23 4001503 HITCH TONGUE CAST U CLEVIS 1
24 622-3511-007 WASHER, FLAT MIL-CARB 5/8 20
25 622-3511-008 WASHER, FLAT MIL-CARB 3/4 1
26 4001271 BUSHING, 4OD-3.5ID SM. FLANGE 2
27 ICO0223 SIDE PIPE CLAMP 12
28 ICO1096 PIN, BOX END 2
29 W915665-4 NUT, NYLOCK 1/2-13 GR5 6
30 4000127 CUTTING EDGE, 8’ GRADER BLADE 2
4000126 CUTTING EDGE, 7’ GRADER BLADE (RIGHT) 2
CUTTING EDGE, 7’ GRADER BLADE (LEFT)
31 ICO1080 STOP, CYLINDER 16” 1
32 ICO1078 PIVOT PIN, CYLINDER 2
33 ICO2153 BOX END RIGHT 1
34 ICO2154 BOX END LEFT 1
35 1-557-010403 1/8” HAIRPIN 1
36 4000419 MANUAL HOLDER 1
37 ICO0226 REAR SIDE CLAMP 1
38 ICO2324 REAR STEER WELDMENT 1
39 ICO2325 REAR STEER AXLE WELDMENT 1
40 ICO1079 1632 DEPTH GAUGE 1
41 1-861-010032-25 WASHER, FLAT 1” 1
42 2000602 DECAL KIT (SEE PAGE 6-30) 1
43 2000616 BOLT KIT (INCLUDES ITEMS 62-77) 1
44 5001147 HYDRAULIC HOSE KIT (SEE PAGE 6-18) 1
45 5001148 HYDRAULIC FITTINGS KIT (SEE PAGE 6-18) 1
46 2000620 LIGHT KIT (SEE PAGE 6-25) 1
