Hub and axle assembly – Landoll ICON 1632RS Grader User Manual
Page 36
6-12
F-740-1213 Edition
ILLUSTRATED PARTS LIST
Hub And Axle Assembly
ITEM
PART NO.
DESCRIPTION
QTY.
ICO0361
HUB AND AXLE ASSEMBLY
2
1
ICO0360
HD16 AXLE 8,500 #
1
2
4001062
HUB SEAL
1
3
4001057
HUB, 7500# 8 BOLT 75-8
1
4
4001061
INNER BEARING
1
5
4000582
OUTER BEARING
1
6
1-861-010032-25
WASHER, FLAT 1”
1
7
1-516-010001-20
NUT, HEX SLOT 1-14
1
8
110-4224
PIN, COTTER 3/16 X 2
1
9
4000585
DUST CAP
1
10
4001060
WHEEL STUD BOLT 5/8-18
8
11
4001059
INNER RACE
1
12
4000580
OUTER RACE
1
13
4001517
WHEEL NUT
8
