ILLUSTRATED PARTS LIST
6-7
47 4001501 HITCH, RING CAT III 1
48 861-10032-24 WASHER, FLAT ZP/CD 1N 3
49 2-150-010008 BUSHING, 1-1/4 OD X 1 ID X 1 STEEL 8
50 4000096 BUSHING 4
51 ICO2189 TRANSPORT STRAP 1
52 SCR2160 WASHER LOAD SHARING PIN
53 173240 TIRE AND WHEEL ASSEMBLY (INCL. ITEMS 16-17, 54) 1
54 TR571 VALVE STEM 2
55 179183 GRADER SNOW/DIRT SKID ASSEMBLY (SEE PAGE 6-34) 1
56 1-654-010055-05 BOLT, HEX 1/2 X 2 GR5 6
57 ICO2187 1632 WEIGHT BOX 1
58 172892 NUT, HEX SLOT 2-1/2-4 1
59 ICO2254 10YD WEAR WASHER 1
60 ICO2255 10YD HITCH RETAINER 1
61 ICO0544 CLAMP, HYD LINE 2
62 141434 SAFETY CHAIN, 21000 LB
63 126561 NUT, FLANGE SERRATED, 5/16-18 11
64 500855 HYDRAULIC VALVE
65 1-654-010049-12 SCREW, HEX HEAD CAP 5/16-18 X 2-3/4 GR5 2
66 103-0625 NUT, ENSA 5/8-11 6
67 122962 SCREW, HEX HEAD CAP 5/8-11 X 4-1/2 GR8 1
68 GRA1599 PIN, CYLINDER 1-1/4
69 63D10ER NUT, HEX 5/8-11 20
70 172827 SCREW, HEX HEAD CAP 5/8-11 X 1-1/2 GR8 4
71 ICO0372 REAR AXLE SUPPORT PIN
72 622-3511-007 WASHER, FLAT MIL-CARB 5/8 1
73 ICO0004 HOSE STAND 1
74 ICO1117 PIN, SPACER 3/4”
75 120876 SCREW, HEX HEAD CAP 3/4-10 X 6-1/2 GR8 1
76 172829 SCREW, HEX HEAD CAP 5/8-11 X 4 GR8 2
77 1-510-010003-09 NUT, FLANGE HEAD SERRATED 1/2-13 2
78 172926 WASHER, MACHINE 2” 4
79 1-654-010055-03 SCREW, HEX HEAD CAP 1/2-13 X 1-1/2 GR5 2
80 622-3511-005 WASHER, FLAT MIL-CARB 1/2 6
81 172830 SCREW, HEX HEAD CAP 5/8-11 X 5 GR8 2
82 172839 NUT, HEX 1-8 GR8 1
83 ICO1082 AGI6C DEPTH GAUGE SPACER
84 ICO1077 UG16 CYLINDER PIN, W/DEPTH GAUGE MOUNT 1
85 ICO1076 UG16 CYLINDER PIN, W/DEPTH GAUGE SLIDE 1
86 ICO1051 UG16 CENTER PIVOT FRAME 1
87 ICO1069 AG16C PIVOT KEEPER 1
88 ICO2183 1632 GRADER TONGUE 1
89 GRA2044 UG16 PIN CENTER BLADE 1
90 ICO1075 CYLINDER PIVOT 2
91 5000 ZERK FITTING, 1/8 8
Grader Assembly
ITEM PART NO. DESCRIPTION QTY.
