Rsb clamp and straight shank assembly – Landoll 2510 Zone Commander User Manual
Page 19
ASSEMBLY
2-11
RSB Clamp and Straight Shank
Assembly
1.
The rigid clamp assemblies are already located on
the frame at the proper spacing.
2.
Attach wearstrip to straight leg shank using wearstrip
bracket, 3/4-10 x 3” hex head cap screw, and 3/4-10
lock nut. (See Figures 2-5 through 2-7)
3.
Attach steel point to straight leg shank using 1/2 x 2”
and 5/16 x 2” spring slotted pins. Place pins with
open ends oriented opposite of each other.
4.
Attach top of shank point assembly to front of spring
clamp assembly using 3/4-10 x 4” hex head cap
screw and lock nut. Attach lower hole of shank point
assembly to rear of spring clamp assembly using
5/8-11 x 5-1/2” hex head cap screw, connex bushing,
and 5/8-11 lock nut.
