ASSEMBLY

2-7

Auto-Reset Clamp and Shank
Assembly

1.

The spring clamp weldments are already located on
the frame at the proper spacing.

2.

Attach wearstrip to straight leg shank using wearstrip
bracket, 3/4-10 x 3” hex head cap screw, and 3/4-10
lock nut. (See Figures 2-2 through 2-4)

3.

Attach steel point to straight leg shank using 1/2 x 2”
and 5/16 x 2” spring slotted pins. Place pins with
open ends oriented opposite of each other.

4.

Attach top of shank point assembly to front of spring
clamp assembly using 3/4-10 x 4” hex head cap
screw and lock nut. Attach lower hole of shank point
assembly to rear of spring clamp assembly using
5/8-11 x 3-3/4” hex head cap screw, connex bushing,
and 5/8-11 lock nut.

5.

Adjustment holes are provided in the spring clamp
weldment to compensate for varying ground
conditions and depths of operation.
