1-6 1P342
SAFETY INFORMATION
Figure 1-4: Safety Signs (2 of 2)
Seed Box May Be Calibrated for Unlisted Seed as Follows:
1. Remove Drive Bolt from 6 Tooth 550 Driver Sprocket.
2. Raise machine & lock in transport position.
3. Place a tarp under machine to collect seed.
4. Turn 15/16 Hex on transmission clockwise as follows:
-136 revolutions - for 8’ Seeders
-109 revolutions - for 10’ Seeders
- 91 revolutions - for 12’ Seeders
5. Weigh seed and multiply by 10 (20 for 26-Tooth Driver)
for approximate planting rate in lbs/acre.
PLANTING RATES FOR SEED BOX
INDICATOR SETTING
POUNDS PER ACRE POUNDS PER 1000 SQ. FT.
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
9K348C
Tightener
13 Tooth
Idler
37 Tooth
Driven
13 Tooth driver
(26 Tooth Optional)
15/16 Hex
* Will crack some seeds at theses settings.
Not recommended: Lentils, Sorgum, Sudan Grass
WARNING !
MOVING PART HAZARD
TO PREVENT SERIOUS INJURY
FROM MOVING PARTS:
• KEEP COVERS CLOSED DURING
OPERATION.
• DO NOT ALLOW ANYONE TO RIDE
OR CLIMB ON MACHINE DURING
OPERATION.
•KEEP OBSERVERS AWAY.
2K123
Same poisition
under Both Covers
Right Cover only
P/N 1K123
Moving Part Hazard
P/N 9K348
Seed Chart
P/N 528933
Reflective Red
P/N 528938
Orange Stripe
