Kinze Grain Carts Rev. 7/14 - Manual (Page 52)

M0238-01 Grain Cart
3-16 5/12
TM
Lubrication and Maintenance
V-BELT REPLACEMENT
NOTE: Drive and driven sheaves (pulleys) do not need to be loosened to remove/replace belts.
NOTE: Cart must be attached to a tractor to use hydraulic system in later steps.
1. Disconnect PTO shaft from tractor.
2. Remove cover and indicator.
3. Remove additional covers.
Remove hardware
Remove cotter pin
and washer
Indicator
