Operation
10. Connect seven terminal breakaway connector for the lighting system on cart to seven pin connector on tractor.
If your tractor is not equipped with SAE Standard 7 terminal connector, obtain through your local tractor supply
dealer. Check clearance lights, signal lights, and auxiliary work light are working properly.
11. Connect optional electric roll tarp and camera harnesses. Check for proper operation.
WARNING
Pressurized hydraulic fluid can penetrate body tissue and result in
death, serious infection, or other injuries. Fluid injected under skin
must be IMMEDIATELY removed by a surgeon familiar with this
type of injury. Make sure connections are tight and hoses and
fittings are not damaged before applying system pressure. Leaks
can be invisible. Keep away from suspected leaks. Relieve pressure
before searching for leaks or performing any system maintenance.
NOTICE
Wipe hose ends to remove any dirt before connecting couplers to
tractor ports or contamination may cause equipment failure.
9. Connect hydraulic hoses to tractor. Kinze grain carts require 5 SCV’s for manual operation and two SCV’s for
remote (joystick) operation (can only be used on a closed center system).
Hydraulic Control Settings
Control Hose color Function
SCV1 Red Auger fold
SCV2 Blue Auger tilt/Remote all
SCV3 Yellow Spout tilt
SCV4 Green Horizontal auger
SCV5 White Flow gate
