Lubrication and Maintenance
GREASE FITTINGS
Those parts equipped with grease fittings should be lubricated at the frequency indicated with an SAE multipurpose
grease. Be sure to clean the fitting thoroughly before using grease gun. The frequency of lubrication recommended on
the following pages is based on normal operating conditions. Severe or unusual conditions may require more frequent
attention.
NOTICE
Extreme operating conditions such as dirt, temperature or speed
may require more frequent lubrication.
Swivel Hitch (Qty. 1)
NOTE: Disconnect PTO from tractor. Retract PTO assembly and rotate shield to expose grease fitting on PTO
slide.
Row Crop Carts (10 Bolt Hub)
Wheel Bearings (Qty. 1 Per Wheel Hub) Flotation Carts (20 Bolt Hub)
Wheel Bearings (Qty. 1 Per Wheel Hub)
ANNUALLY
7100-277
NOTICE
Dust cap must be loosened or removed to while greasing, to
prevent damage to seal.
WEEKLY
7100-110
