Planter Configuration
CONFIGURATION wIZARd
Page 1 - Select planter model by tapping on model box to bring up complete list. Select your model, number of rows
and row spacing.
Page 2 - Select your clutch, electric or pneumatic. If equipped with a hydraulic seed meter drive, click in the gray box
so a checkmark appears.
CONFIG
3:00 PM
Kinze 3800 24 Row 30 in
Planter Model
CONFIG WIZARD
Configuration Wizard - Page 1
TC
Prev
Next
3:00 PM
Electric
Clutch Type
Hydraulic Seed Meter Drive Equipped:
CONFIG WIZARD
Configuration Wizard - Page 2
TC
Prev
Next
F
Prev
Model Box
