Kinze 3140 Stack Fold Planter Rev. 7/14 - Manual (Page 12)

M0245-01 Model 3140
1-6 9/12
TM
TRACTOR HYDRAULIC REqUIREMENTS - MECHANICAL
Configuration Requirements Description
Base machine with mechanical
meters
1 SCV 10 gpm #1 SCV: Planter fold
Base machine with mechanical
meters and optional row marker
package
2 SCV 20 gpm
#1 SCV: Planter fold
#2 SCV: Row markers with sequencing/flow control valve
Base machine with mechanical
meters, optional row markers and
dual lift assist package
3 SCV* 20 gpm
#1 SCV: Planter fold
#2 SCV: Row markers with sequencing/flow control valve
#3 SCV: Dual lift assist
Base machine with mechanical
meters, optional row markers,
dual lift assist package, and wing
down flex package
4 SCV* 20 gpm
#1 SCV: Planter fold
#2 SCV: Row markers with sequencing/flow control valve
#3 SCV: Dual lift assist
#4 SCV: wing down flex
*Some options may be combined to reduce the number of SCV outlets required.
TRACTOR HYDRAULIC REqUIREMENTS - EDgEVAC
Configuration Requirements Description
Base machine with vacuum
meters (external case drain
required for EdgeVac hydraulic
circuit)
2 SCV 25 gpm
#1 SCV: Vacuum meters
#2 SCV: Planter fold
Base machine with vacuum
meters and optional row marker
package (external case drain
required for EdgeVac hydralulic
circuit)
3 SCV 35 gpm
#1 SCV: Vacuum metering
#2 SCV: Planter fold
#3 SCV: Row markers with sequencing/flow control valve
Base machine with vacuum
meters, optional row marker
package, and dual lift assist
package option (external case
drain required for EdgeVac
hydralulic circuit)
3 SCV* 35 gpm
#1 SCV: Vacuum meters
#2 SCV: Planter fold
#3 SCV: Row markers with sequencing/flow control valve
#4 SCV: Dual lift assist package
#5 SCV: Wing down flex package
*Some options may be combined to reduce the number of SCV outlets required.
Specifications
