Kinze 3140 Stack Fold Planter Rev. 7/14 User Manual

Page 11

Model 3140

M0245-01

9/12

1-5

Specifications

SPECIFICATIONS

Planter Size

12 Row 30"

12 Row 36"/38"

12 Row 38"/40"

16 Row 30"

Width - Transport
(Without Markers)

16'-1" (4.9M)

18'-5" (5.6M)

21'-1" (6.4M)

Width - Transport
(Includes Markers)

17'-9" (5.4M)

19'-6" (5.9M)

22'-2" (6.8M)

23'-0" (7.0M)

Width - Planting

30'-0" (9.1M)

37'-4" (11.4M)

40'-0" (12.2M)

Height - Transport
(Without Markers)

12'-6" (3.8M)

Height - Transport
(With Markers)

15'-6" (4.7M)

Weight (Mechanical)

6236 lb. (2828.6 kg)

6541 lb. (2966.9 kg)

6621 lb. (3003.2 kg)

7480 lb. (3392.9 kg)

Weight (EdgeVac)

6794 lb. (3081.7 kg)

7127 lb. (3232.7 kg)

7214 lb. (3272.2 kg)

8109 lb. (3678.2 kg)

Toolbar (Mechanical)

7" x 7" x ¼" wall

7" x 7" x ⅜" wall

Toolbar (EdgeVac)

7" x 7" x ⅜" wall

Seed Capacity

1.75 bu. (EdgeVac/Hopper); 1.90 bu. (Mechanical/Hopper)

Tires

Four 7.60" x 15" 8 ply - adjustable height

Drive System

Two 4.10" x 6" spring-loaded contact drive tires with no. 40 chain

Seed Transmission

Two wheel module-mounted, quick-adjust with machined sprockets and no. 40 chain

Drive/Drill Shafts

⅞

" hex drive/drill shafts

gENERAL INFORMATION

The Model 3110 Mounted Planter is available with EdgeVac or mechanical meters, conventional hoppers, and various
other options. Contact your Kinze dealer for additional options which may be available for your specific model year planter.

Information in this manual was current at time of printing. However, due to Kinze’s ongoing product improvement,
production changes may cause your machine to appear slightly different in detail. Kinze Manufacturing, Inc. reserves the
right to change specifications or design without notice and without incurring obligation to install the same on machines
previously manufactured.

Right hand (R.H.) and left hand (L.H.), as used throughout this manual, are determined by facing in the direction the
machine will travel when in use, unless otherwise stated.
