8 Supplement

8.1

Technical data

Analog input

Measuring input

Pt1000 as per DIN EN 60751 in 3-wire circuit

Operating temperature range

-30 to +260 °C for basic type 902930/10 and 902930/20
-50 to +600 °C for basic type 902930/12 and 902930/22
-200 to +600 °C for basic type 902930/50 and 902930/60
(refers to the sheath up to approx. 20 mm beneath the handle)

Accuracy
of the temperature probe

Class A ±(0.15 K + 0.002 x ItI)
ItI = measured temperature in °C without prefix

Sensor lead resistance

11 Ohm per lead with 3-wire circuit

Probe current

500 µA

Measuring circuit monitoring

Detection of probe break and short-circuit

Output (radio transmission)

Probe ID

max. 5-digit ID, factory setting,
customer-specific configuration possible

Transmission interval

adjustable from 1 to 3600 s;
factory setting
for basic type 902930/10, 902930/12 and 902930/50 = 10 s
factory setting
for basic type 902930/20, 902930/22 and 902930/60 = 15 s

Transmission frequency

ISM band 868.4 MHz (Europe);
915 MHz (America, Australia, Canada and New Zealand);
ten frequencies can be set in the 915 MHz band

Transmission capacity

<

+ 10 dBm

Open air range

300 m for 868.4 MHz, 100 m for 915 MHz
and when using the antenna wall holder for the receiver and the
3 m long antenna cable. When installing the antenna directly onto
the receiver, a reduced range of approx. 40 % must be taken into
account.

Output signal

882.2 to 1977.1 Ohm = -30 to +260 °C
810.6 to 3137.1 Ohm = -50 to +600 °C
185.2 to 3137.1 Ohm = -200 to +600 °C

Response time
of the complete probe

t

0.9

10 s

Calibration accuracy of the
electronic components

±0.05 %

1

1

All accuracy specifications in % relating to the measuring range of 290 K or 800 K.

Configuration

with setup program

configurable parameters

Probe ID (max. 5-digit ID), transmission interval,
transmission frequency (with 915 MHz only)
