2 Identifying the device version
14
(1) Basic type
902930/20
Wtrans probe T02.G1
Insertion RTD temperature probe
Ambient temperature, handle: -25 to +125 °C
(2) Operating temperature in °C
x
596
-30 to +260 °C
(3) Measuring insert
x
1006
1x Pt1000 in 3-wire-circuit
(4) Tolerance class as per DIN EN 60751
x
2
Class A
(5) Sheath diameter D in mm
x
1.9
Ø 1.9 mm (particularly quick responding) stepped from Ø 4 mm
to Ø 1.9 mm, available with flat probe tip only
x
4
Ø 4 mm
x
4.5
Ø 4.5 mm
x
6
Ø 6 mm
(6) Fitting length EL in mm (EL 50 to 1000)
x
100
100 mm
x
150
150 mm
x
200
200 mm
x
...
Please specify in plain text (50 mm steps)
(7) Insertion tip
x
1
Flat
x
2
Concentric, angled at 25°
x
3
Oblique, angled at 45°
(8) Transmission frequency
x
10
ISM band 868.4 MHz (Europe)
x
20
915 MHz (America, Australia, Canada and New Zealand)
(9) Process connection
x
000
None
x
103
Screw connection G 3/8
x
104
Screw connection G 1/2
x
253
Pipe screw connection G 3/8 (for sheath diameter 6 mm only)
x
254
Pipe screw connection G 1/2 (for sheath diameter 6 mm only)
x
255
Pipe screw connection G 3/4 (for sheath diameter 6 mm only)
x
263
Pipe screw connection M 10x1 (for sheath diameter 6 mm only)
x
291
Pipe screw connection 1/2-14NPT (for sheath diameter 6 mm only)
x
662
Sheet steel flange (for sheath diameter 6 mm only)
(10) Extra codes
x
000
None
x
778
Customer-specific transmission interval, factory setting 15 s
(for orders, specification in plain text between 1 to 3600 s)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
Order code
-
-
-
-
-
-
-
-
/
Order example
902930/20 - 596 - 1006 -
2
- 4 - 100 - 2 - 10 - 000 / 000
