Page 23

23
3 Probe preparation
3.5
Fitting the color coding of a probe
Figure 6:
Fitting the color coding of a probe
The probe delivery scope includes four color rings made of silicon (white, green, red and blue)
to be used to clearly identify the probes visually.
Proceed as follows to be able to identify the probes:
1
Top color code
2
Bottom color code
Step
Activity
1
To fit a clear combination of silicon rings to the probe, push the rings onto the probe shank.
2
Note down the probe color combinations.
1
2
TIP!
Color caps (colored handle sections in gray, brown, green or blue) for the visual probe iden-
tification are available as accessories as an alternative to the color rings.
The color caps can be replaced by screw-on handle sections.
