Approvals/marks of conformity
For all types
Electrical data
Environmental influences
Housing
Setup interface
The setup interface is used for configuring the transmitter from a PC. Connection is via the PC interface with a TTL/RS232 converter (or
an USB/TTL converter) and adapter.
Fine calibration
Fine correction means correction of the output signal. The signal can be corrected in the range ± 5 % of the 20 mA end value.
Fine calibration is performed using the setup program.
On type 707021/..., type 707022/... and 707025/... fine calibration can also be carried out from the instrument keys.s
Mark of
conformity Testing
laboratory Certificates /
certification numbers Test basis valid for
II (1) G [Ex ia Ga] IIC
II (1) D [Ex ia Da] IIIC PTB PTB 01 ATEX 2149 EN 60079-0:2009
EN 60079-11:2012 Type 707025/...
[Ex ia Ga] IIC
[Ex ia Da] IIIC PTB IECEx PTB 14.0034 IEC 60079-0:2011
IEC 60079-11:2011 Type 707025/...
Electrical safety to EN 61010
Electromagnetic compatibility (EMC)
- interference emission
- immunity to interference
EN 61326-1
Class B
to industrial requirements
Ambient/storage temperature range -10 to +60°C / -10 to +70°C
Temperature error
 ± 0.005% per °C deviation from 22°C a
Climatic conditions < 75% rel. humidity, no condensation
a
All specifications refer to the range-end value 20mA
Material polyamide (PA 6.6)
IP protection IP20 (EN 60529)
Screw connection screw terminal 0.2 — 2.5mm²
Mounting on 35mm x 7.5mm DIN rail to EN 60715
Operating position upright
Weight approx. 50g
Configurable parameters
TAG number (6 characters on
type 707020/...,
for all the others: 10 characters) Sensor type Connection circuit (2-/3-/4-wire)
External and internal cold junction Customized linearization Range limits
Selection of type lk7 or lk8
(not on type 707020/...) Input of limit
(not on type 707020/...) Input of differential (upper and lower)
(not on type 707020/...)
Output signal rising/falling
(inversion) Digital filter Response to probe break/short-circuit
Recalibration (fine calibration) Lead resistance for 2-wire circuit
